Ip66 Waterproof Outdoor Tunnel Pathway PIR LED Flood Light 20W 50 Hz 60Hz ≥120lm/W
Features:
| Power: | 20w |
| Material: | Aluminum Alloy/PC |
| Chip: | Luminleds Luxeon |
| Light efficiency: | 90-130Lm/w |
| Color Temperature: | 2700 -3000K 4000-4500K 5000-6000K |
| CRI: | Ra70 |
| Beam Angle: | 120 degree |
| PF: | >0.95 |
| Working Life: | ≥ 50000 hrs |
| Warranty: | 3 years |
| Dimensions |
| Finishing Color: | Black |
| Wire connection: | L(Brown);N(Blue);G(Green/Yellow) |
| SHAPE: | Rectangle |
| Package: | 2pcs/carton |
| Work Environment |
| Input Voltage: | AC100-240V/50-60Hz |
| Operating Temperature: | -40~ + 60°C |
| Application |
| Application: | Projector / Floodlight
Tunnel Lighting / Pathway Lighting / Park Lighting
Signboard Lighting |
| Recommend mounting height: | 3-6m |
1. Adopting high power integrated LED, which ensures light is more uniform,light efficiency is higher.
2. Using high transmittance tempered glass,transimittance93%
3. Complying with ROHS,absolutely not contain mercury or other harmful substance
4. Lifespan of whole tube over 35000 hours
5. LED lamp turn on automatically when the body through the sensor area.
6. Can identify day and night automatically, the ambient-light can be selected to work at night automatically and stop in the daytime.
7. Time-delay can be adjusted vary to the place.
Technical Data:
| Material | Die-cast Aluminum |
| Input Voltage | AC100-240V 50/60Hz |
| Power Efficiency | ≥85% |
| Power factor | ≥0.95 |
| Beam Angle | 120º |
| LED Luminous efficiency | ≥90lm/W |
| Color Temperature | Warm white WW 2800-3500K
Neutral white NW 4000-5000K
Pure white PW 5500-7000K |
| Detection range | 120º |
| Detection distance | 12m |
| Time-delay | Min:5sec Max:6min±2min |
| Ambient-light | <3Lux-2000Lux |
| Installation | height:2m-4.5m |
Product Descriptions:
| Model | Product Dimension(mm) | Power (W) | LED Luminous flux | Average Iilluminance | Facula Area | Net Weight |
| LY-FL1010PW-P | L115xW85xH106 | 12 | 760-860lm | 1m=289lux
2M=72lux
3M=32lux | 1M=3.5x3.5M
2M=6.5x6.5M
3M=9.5x9.5M | 0.65KG |
| LY-FL1020PW-P | L225xW230xH125 | 25 | 1700-1900lm | 2m=110lux
3M=50lux
4M=30lux | 2M=3.5x3.5M
3M=6.5x6.5M
4M=9.5x9.5M | 2.13KG |
| LY-FL1030PW-P | L225xW230xH125 | 35 | 2550-2850lm | 2m=155lux
3M=75lux
4M=45lux | 2M=3.5x3.5M
3M=6.5x6.5M
4M=9.5x9.5M | 2.14KG |
| LY-FL1050PW-P | L285xW270xH135 | 55 | 4250-4750lm | 4m=80lux
6M=35lux
8M=18lux | 4M=9x9M
6M=14x14M
8M=19x19M | 2.98KG |
Product dimension(mm) Optical Parameters:
Features
- Multi-Chip on Lead Frame, Single Module LED Package Design
- System Design Integrating Power Supply, LED Light Engine, and Heat Sink
- Over Current, Over Voltage, Over Heat, Thunder Protection
- Choice of Correlated Color Temperatures(Specification Re-Defined Accordingly)
- Long lifespan for LED 50,000 hrs
- 100% Recycle, No Pollution, and UV, IR
Operation and Storage Condition
- Operation Ambient Temperature -40 to +60°C, Relative Humidity 20~90%
- Input Voltage 85-265V AC, 50/60Hz
- Storage Ambient Temperature -40 to +85°C, Relative Humidity 5~95%
- Mounting Height : Suitable for 8~10mheight
Certificate
- The Whole Spotlight Certificated with ROHS
- The Whole Spotlight Certificated with CE
Applications:
Suitable for workshop, factory, garden, road and other automatic control occasion.
Shenzhen Leyond Lighting Co.,Ltd. was founded in 2005 which is the wholly-owned subsidiary of LiYang Electronic(Hongkong)Limited. We are High-Tech enterprise who concentrate and specialize in developing and producing Eco-friendly high power LEDLightings.
Leyond company is located in Shenzhen, owns a 6000m2 factory with high qualified clear workshops and 300 employees. Together with outstanding optical & technical personnels and quality engineers; equipped with advance automaticity Die Bonding & chip bondingequipments and molding machines; perfect quality-testing and safeguard measures; all of these promote Leyond to be the leader in the industry.
“Innovation is the base of development; qualified service is the foundation of existence”, Leyond keeps up with marketing trendbased on customers’ requirements, try to supply the best products with best price & quality and humanistic service.
LEYOND is the Top 3 LED street light exporter from China,Our major products include Led Street lights, Led flood
light,Stadium&Large Area Lighting,Led Canopy lights,ect,All design and making by ourself. According to customers’ requirement we can supply professional lighting solution not only design but also in production. Leyond operates strictly based on ISO 9001:2000,the quality management system from purchasing to designing to manufacturing.
Our products are exported to Europe, Americas, Africa and other Asian countries with ROHS,CE and CB international standard.
Also we have flexible and timely after-sales services. We offer high quality products and sustainable service to our customers,establishing long-term cooperative relationship with them.
